The Merida eOne-Eighty 500 Electric Enduro Bike is engineered for tackling the most challenging trails with confidence. It combines cutting-edge eMTB technology with robust components, featuring a powerful Bosch Performance Line CX motor and an 800Wh battery for exceptional performance on steep climbs and rugged descents. With advanced suspension and high-quality tires, this bike is built to deliver a thrilling ride on any terrain.
Merida eOne-Eighty 500 Electric Enduro Bike Gunmetal Grey/Black
- Rockshox Zeb Base eMTB shock 180mm travel
- Rock Shox Zeb Select eMTB fork 180mm travel
- Bosch Performance Line CX motor - ready for 100Nm upgrade
- Shimano CUES U6000 10-speed drivetrain
- Maxxis Assegai and Minion DHR II tires
Powerful Bosch Motor and Long Battery Life
Equipped with the Bosch Performance Line CX motor and an 800Wh battery, the Merida eOne-Eighty 500 delivers consistent power and an impressive range. Whether you're tackling steep climbs or extended trail rides, the motor and battery combination ensures smooth, reliable performance.
Exceptional Suspension for Rough Trails
With 180mm front and rear suspension travel provided by RockShox Zeb components, this e-bike handles rough terrain with ease. The advanced suspension system absorbs shocks, giving you full control over rocky descents and technical sections.
Precise Shifting and Reliable Braking
The Shimano CUES U6000 10-speed drivetrain provides smooth and accurate gear changes, while Tektro hydraulic disc brakes with 203mm rotors ensure consistent stopping power. This combination gives you the confidence to push your limits on any trail.
What is the Merida eOne-Eighty 500 used for?
The Merida eOne-Eighty 500 is designed for aggressive trail riding and enduro mountain biking. It excels at handling technical descents, rough terrain, and challenging climbs with the help of its powerful motor and advanced suspension.
Why choose the Merida eOne-Eighty 500?
The Merida eOne-Eighty 500 offers a powerful Bosch motor, a large 800Wh battery for extended rides, and high-performance suspension. Its top-tier components, including Shimano shifting and Tektro brakes, make it a reliable choice for tackling demanding trails.
Who is the Merida eOne-Eighty 500 designed for?
The Merida eOne-Eighty 500 is designed for mountain bikers who seek adventure on challenging trails. It's perfect for riders who need the extra power of an e-bike while still wanting to maintain control and performance on tough descents and climbs.
| SKU | Merida2525eONEEIGHTY500I1GUNMETALGREY |
|---|---|
| Season | 2025 |
| Sizing SKUs | SM: MEEB2503258, MD: MEEB2503259, LG: MEEB2503260, XL: MEEB2503261 |
| Click & Collect | Yes |
| Shipped Nationally | Yes |
| eBike Drive System | Mid Drive |
| Motor Brand | Bosch |
| Motor Model | Performance Line CX |
| Motor Torque (Nm) | 85 Nm |
| Motor/Drive Unit | Bosch Performance Line CX; 250W; 85Nm (upgradeable to 100Nm); 25KPH |
| Battery | Bosch PowerTube 800 |
| Battery Brand | Bosch |
| Battery Size (Watt-Hours) | 800 W-h |
| Battery Model | PowerTube 800 |
| Display | Bosch Purion 200 |
| Colour | Grey |
| Frame | Aluminium; 180mm suspension travel; 27.5" x 2.6" max. wheelsize; 148x12mm axle standard |
| Frame Material | Alloy |
| Fork | Rockshox Zeb Base eMTB; Air; 180 STR; Tapered; 44mm fork offset; 29x2.6" max WHS |
| Fork Brand | RockShox |
| Front Travel | 180mm |
| Rear Travel | 180mm |
| Rear Shock | Rock Shox Vivid Base |
| Speeds | 1 x 10 |
| Front Gears | Single |
| Groupset Brand | Shimano |
| Groupset | Shimano Cues |
| Rear Gears | 10 Speed |
| Crankset | FSA CK-220 wide E-Bike Forged Crankset; 165mm |
| Pedals | VP VPE-533 |
| Chain | Shimano LG500 |
| Brake Type | Hydraulic Disc Brake |
| Brakes | Tektro Gemini M535 |
| Derailleur Rear | Shimano CUES U6000 |
| Cassette | Shimano Cues LG400 11-48T; 10 Speed |
| Wheel Size | 29" / 27.5" (Mullet Bike) |
| Tyres | F: Maxxis Assegai; 29x2.5"; fold; TR EXO+ 3C MaxxGrip | R: Maxxis Minion DHR II; 27.5x2.4"; fold; 3C DD TR MaxxTerra |
| Rims | MERIDA EXPERT TR II |
| Hubs | F: Shimano TC500 | R: Shimano TC500 |
| Headset | Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
| Grips | MERIDA EXPERT EC |
| Stem | MERIDA EXPERT eTR II |
| Seatpost | MERIDA EXPERT TR II |
| Weight | 27kg |
Merida eOne-Eighty Sizing Chart
This is an accurate estimate, and every new bike comes with a free professional bike fit when you click & collect in store, plus all bikes have a 30 day Perfect Ride Guarantee.
Legend
ST Seat Tube
TT Top Tube
CS Chain Stay Length
HTA Head Tube Angle
STA Seat Tube Angle
BD Bottom Bracket Drop
HT Head Tube
FL Fork Length
R Reach
S Stack
WB Wheel Base
|
Size |
SM | MD | LG | XL | Wheel Size | 29" / 27.5" (Mullet Bike) | 29" / 27.5" (Mullet Bike) | 29" / 27.5" (Mullet Bike) | 29" / 27.5" (Mullet Bike) | Frame Size | SM | MD | LG | XL | ST Seat Tube (mm) | 410 | 425 | 445 | 465 | TT Top Tube (mm) | 577 | 604 | 630 | 652 | CS Chain Stay Length (mm) | 435 | 435 | 435 | 435 | HTA Head Tube Angle (°) | 64.5 | 64.5 | 64.5 | 64.5 | STA Seat Tube Angle (°) | 78.5 | 78.5 | 78.5 | 78.5 | HT Head Tube (mm) | 115 | 120 | 125 | 130 | R Reach (mm) | 435 | 460 | 485 | 505 | S Stack (mm) | 657 | 661 | 666 | 670 | WB Wheel Base (mm) | 1218 | 1245 | 1272 | 1294 |
